Eaton IEC Magnetic Contactor, 1NO, 24V AC, 3 P, Non-Reversing, Screw XTCE018C10T

The Eaton XT IEC contactor is an IEC magnetic contactor used to switch power circuits. It is a 3-pole, non-reversing device with 1 normally open auxiliary contact and screw terminals. The coil voltage is 24V AC, and it is rated for continuous operation at specified current levels under normal conditions: 18 A (inductive) and 40 A (resistive). It is rated for operation within the specified voltage ranges, with mounting on DIN Rail or panel; does not include an enclosure; suitable mounting options available. Key features: - Action: Non-Reversing (controls current flow in one direction) - Coil Voltage: 24V AC - Auxiliary contacts: 1NO; Includes auxiliary contacts: Yes - Contact Configuration: 1 NO - Frame/Series: Frame C; Series XT; Contactor Style: IEC - Full Load Amps: rated for continuous operation at specified current levels under normal conditions: Inductive 18 A; Resistive 40 A - Maximum Voltage Rating: 690V AC - Certifications/Standards: UL Listed; CSA Certified; IEC 60947; EN 60947; CE Marked; RoHS - Electrical/Durability: Designed to withstand specified electrical and mechanical cycling under standard testing conditions - Enclosure/Protection: IP20; Enclosure NEMA Rating: does not include an enclosure; suitable mounting options available - Mounting: DIN Rail, Panel - Dimensions: Width 3.5 in; Height 1.5 in; Depth 4 in - Maximum/Minimum Operating Temperature: 122 Degrees F / -13 Degrees F - Terminals: Electrical Connection: Screw - Product Identity: Item – IEC Magnetic Contactor; Product Name – Eaton XT IEC contactor
