1 hp 1075 RPM 3-Speed 48 Frame 208-230V Direct Drive Furnace Motor Century # BD1106

1 hp 1075 RPM 3-Speed 48 Frame 208-230V Direct Drive Furnace Motor Century # BD1106

(No ratings yet)

Key item features

  • 1 hp 1075 RPM, 5.1 amps, 208-230 Volts
  • 3-Speed
  • Service Factor = 1.0
  • Includes 20 MFD 370V Capacitor
  • 5.6" Diameter, Motor Body Length 5 1/4""
  • 1/2" x 6.44" shaft, Rotation Reversible
  • 22" Leads
  • Extended thru bolts shaft end
  • Ball Bearings.
  • One year warranty.

Permanent Split Capacitor Motor. 2 1/4" Resilient Rings. Belly Band or Stud Mount. Automatic Overload Protection. Continuous Duty; Easy Rotation Change; Enclosure; Continuous Duty; Class B Insulation; Residential Application; 40C Ambient Temperature; These motors will work in most "Belly Band Applications" meaning if the motor is mounted via a strap/clamp around the body of the motor or mounts with the motor "thru-bolts. Belly band brackets available: Torsion Flex Bracket (3-Prong) # 2MEY7, Torsion Flex Bracket (4-Prong) # FM554, Welded 3-Ring Bracket # 2MEV4.
Dayton 48Y526

Current price is $352.86
Price when purchased online
  • Free shipping
  • Free 30-day returns
