Celestion 10-in Mid/bass driver 8 ohms w/Kevlar loaded paper
Celestion 10-in Mid/bass driver 8 ohms w/Kevlar loaded paper
Hero image 0 of Celestion 10-in Mid/bass driver 8 ohms w/Kevlar loaded paper, 0 of 7

Celestion 10-in Mid/bass driver 8 ohms w/Kevlar loaded paper

(No ratings yet)

Key item features

  • 10-in Mid/bass driver delivering 99dB sensitivity and 300Wrms (AES standard)
  • Power handling
  • FEA optimised magnet assembly and suspension delivers highly symmetrical
  • cone movement leading to exceptionally low harmonic distortion
  • Balanced Airflow Venting (BAV) increases airflow to provide enhanced cooling
  • Twin demodulation rings reduce flux modulation, minimizing electromagnetic
  • distortion
  • M-roll surround provides progressive excursion control, yielding a smooth
  • response even at extremes of frequency range
  • Nominal diameter: 254mm/10in
  • Power rating: 300Wrms
  • Continuous power rating: 600W
  • Nominal impedance: 8 Ohms
  • Sensitivity: 99dB
  • Frequency range: 60-5,000 Hz
  • Voice coil diameter: 64mm/2.5 in
  • Chassis type: Cast Aluminium
  • Magnet type: Ferrite
  • Magnet weight: 1.7 kg/60oz
  • Coil material: Edgewound copper clad aluminium
  • Former material: Glass fibre
  • Cone material: Kevlar loaded paper
  • Surround material: Cloth-sealed
  • Suspension: Single
  • Xmax4: 2.5 mm/0.1 in
  • Gap depth: 8mm/0.31 in
  • Voice coil winding width: 12.5 mm/0.49 in
  • Small Signal Parameters
  • D: 0.21 m/8.27 in
  • Fs: 54.8 Hz
  • Mms: 37.03 g/1.31 oz
  • Qms: 2.338
  • Qes: 0.299
  • Mmd: 32.51 g/1.15 oz
  • Qts: 0.265
  • Re: 5.15O
  • Vas: 38.63 lt/1.36 ft3
  • BI: 14.82 Tm
  • Cms: 0.23 mm/N
  • Rms: 5.46 kg/s
  • Le (at 1kHz): 0.57 mH Mounting Information
  • Overall diameter: 265 mm/10.43 in
  • Overall depth: 119 mm/4.69 in
  • Cut-out diameter: 230.8 mm/9.1 in
  • Mounting slot dimensions: 8x6.5 mm/0.3x0.25 in
  • Number of mounting slots: 8
  • Mounting PCD range: 244.5-247 mm/9.63-9.73 in
  • Unit weight: 4.9kg /10.8 lb
  • Packed Dimensions Weight
  • Single pack size W x D x H: 306 mm x 306 mm x 155 mm: /12 in x 12 in x 6.1 in
  • Single pack weight: 5.5kg /12.1 lb
