101AV 4CH Security System Hybrid HD H.265+/H.264 5in1 DVR, HD-TVI/CVI/AHD/IP, No HDD, 1080P HDMI/VGA Video Out, Phone APPs for Home & Office, Work w/ 5MP Lite Analog & 4MP IP Camera

Features :
1. Remote access, Anytime Anywhere with mobile viewing and alarm notifications.

2. Keep your old analog cameras and upgrade your old/analog CCTV system to Cloud/IP based network system for remote access anytime anywhere capability.

3. Reliable & user-controlled storage that is confidential. Storage is local and not on the cloud, which decreases risk of cyber attacks.

4. Comprehensive range of Super High Definition product line, including cameras, DVRs/NVRs, and Super HD monitors

5. "5-Star Best-Seller" rating with over 1000+ customer reviews

6. Top rated US-based live telephone customer service with 5 star rated customer feed backs

7. Motion/alarm notifications via cell phone/pad/PC/DVR with audio beeping and full page display call-up on local monitors.


[Safe and Dependable]
1. U.S TEL. local service, Tech Support#1-408-720-0029, 8AM-5PM Monday to Friday, California Time

[5-in-1 Hybrid 5MP DVR]
1. DVR can connect 4 HD/SD cameras by using wired cable with BNC connectors and 1 IP Network cameras by using IP address
2. Support 1 x SATA HDDs(Each HDD can up to 8TB).
3. Exceptionally strong password and anti-hacking protocols to increase privacy and security. Snapshot, and Email notifications for real time protection.
4. Up to 1080P HDMI and VGA Video Output Resolution. USB Backup files.

[Advanced H.265+ High Efficiency Video Format]
1. H.265+ can further improve compression ratio on the basis of H.265 standard
2. It can save about 75% storage compared with H.264 and thus effectively saving storage resources and provides an excellent and smooth viewing experience.

[Pre-Alarm Recording and Motion Detection]
1. Motion activated full screen alarm call up protection with optional audible warning.
2. Dual-stream: network video and local recording.

[User friendly setup instructions]
1. Including QIG (Quick Installation Guide) for PC based VMS/CMS integration.
2. Cloud based cell phone APPs for both Android and iPhone without confusing port forwarding, and real time Snapshot alarm notification. There are options to show 1, 4, and 8 cameras simultaneously on both the mobile APP on cell phone and also the Central Monitoring Software (CMS) on PC.

Specifications :

• Video Input：4 Channels
• HD-TVI/HD-AHD：5MP,4MP,1080P,720P
• HD-CVI：5MP,4MP,1080P,720P
• CVBS：PAL/NTSC IP CAM： 4MP,4chs (only IP up to 8chs)
• Video Output：HDMI(1080P@60Hz/720P)/VGA(1080P@60Hz/720P)
• Remote Connections：128
• Network Protocols：TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, ONVIF
• Incoming Bandwidth：40Mbps
• Outgoing Bandwidth：48Mbps
• SATA ：1 SATA Interface Capacity(Up to 3TB/HDD)
• Two-Way Audio Input：1CH, RCA
• Network Interface：RJ45 10M/100M self-adaptive Ethernet interface
• Serial Interface：RS-485 Half-duplex
• USB Interface：2 x USB2.0
• Power Supply：12VDC
• Consumption：≦ 8W
• Working Temperature：14°F ～131°F
• Working Humidity：≦ 90%
• Dimensions：10.2 x 9.4 x 1.8 inch
• Weight：1.1 kg (2.42lb)
