100W Vibration Motor Vibrator Single Phase Vibrating Sieve Industrial 3000rpm

100W Vibration Motor Vibrator Single Phase Vibrating Sieve Industrial 3000rpm

Description:
100w Vibration Motor 110v Industrial Vibrator Single Phase

Specifications:

Name: Vibrator Motor
Rated Speed: About 3000 Rpm
Rated Voltage: 110v
Type: 1 Phase 100w
Current: 0.45a
Force: 50kg
Product Size: 17*11*7.5cm
Net Weight: 2.3kg
Note: to Meet the Installation Needs of Different Customers, Our Motors Do Not Include Plugs

Features:
1. Adjustable Eccentricity Block: Adjust the Angle of Eccentricity Block, Can Stepless Adjust the Excitation Force , Meet All Kinds of Requirements
2. Adopt of Imported Bearings, Low Noise, Smooth Operation, Long Service Life
3. High Temperature Resistance Pure Copper Enameled Wire, All Copper Winding, Stator Vacuum Dip Paint, Guarantee Insulation Grade
4. Aluminum Alloy Shell, Light Quality, Fast Heat Dissipation, Fast Temperature Rise
5. The Machine Shell Is Precision Casting, with O-ring Seal on the Edge, Fully Closed Structure Design, with Dustproof and Moisture-proof Function
6. Anti Vibration Special Power Cable Protection Cover to Prevent Long - Time Cable Vibration Damage
7. Apply in Mining, Metallurgy, Coal, Electricity, Construction, Chemicals, Medical Equipment, Food Machinery, Etc

Wiring Method:

1 Phase: Green and Yellow Wire: Ground Wire, the Other Two Wire: One Connect Neutral Live, One Connect Live Wire (Arbitrarily)

Package Included:

1 X Vibrator Motor
