Cisco WS-C3560V2-24PS-E 24-Port PoE 3560V2 24PS Catalyst Switch Product Name Cisco Catalyst 3560V2-24PS Product Code WS-C3560V2-24PS-E Condition Used, TESTED working 100% in good condition. Product Features SPECIFICATIONS Product Description Cisco Catalyst 3560V2-24PS - Switch - L3 - managed - 24 x 10/100 + 2 x SFP - rack-mountable - PoE Device Type Switch - 24 ports - L3 - managed Status Indicators Port status, link activity, port transmission speed, port duplex mode, status Features Flow control, layer 3 switching, auto-sensing per device, DHCP support, auto-negotiation, ARP support, load balancing, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, IPv6 support, event log, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, Dynamic ARP Inspection (DAI) Authentication Method Kerberos, RADIUS, TACACS+, Secure Shell v.2 (SSH2) Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s Interfaces 24 x 10Base-T/100Base-TX - RJ-45 - PoE 1 x console - RJ-45 - management 2 x SFP (mini-GBIC) Power Device Power supply - internal Voltage Required AC 120/230 V ( 50/60 Hz ) Enclosure Type Rack-mountable - 1U Ports 24 x 10/100 + 2 x SFP Power Over Ethernet (PoE) Yes MAC Address Table Size 12K entries Remote Management Protocol SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, SSH-2 Flash Memory 32 MB flash Power Consumption Operational 435 Watt Routing Protocol OSPF, IGRP, BGP-4, RIP-1, RIP-2, EIGRP, HSRP, DVMRP, PIM-SM, static IP routing, PIM-DM, policy-based routing (PBR) DIMENSIONS Width 17.4 in 44.2 cm Depth 11.6 in 29.5 cm Height 1.7 in 4.3 cm Weight 10.1 lbs 4.6 kg SUITABLE CONDITIONS Min Operating Temperature 32 °F .0 °C Max Operating Temperature 113 °F 45.0 °C Humidity Range Operating 10 - 85% The Cisco Catalyst 3560 v2 Series is the next-generation energy-efficient Layer 3 fast Ethernet switches. This series of switches supports Cisco EnergyWise technology, which enables companies to measure and manage power consumption of network infrastructure and network-attached devices, thereby reducing their energy costs and their carbon footprint. The Cisco Catalyst 3560 v2 Series consumes less power than its predecessors and is the ideal access layer switch for enterprise, retail, and branch-office environments, as it maximizes productivity and investment protection by enabling a unified network for data, voice, and video.
