Anqidi 8000W Voltage Converter Transformer 110V to 220V 220V to 110V Step Up/Down Transformer Heavy Duty

To Convert 110V to 220V

1.Make sure the appliance to be plugged in uses fewer watts than the transformer's rating.

2.Insert the voltage tap plug (located on the rear of the transformer) into the pair of holes marked "110".

3.Plug the transformer's power cord into a source of 110 volts.

4.220 volts will be available at the front panel outlet marked "220" volts when the power switch is turned on. (Please note that the front socket supports electrical devices with a current of up to 13A, devices above 13A must be connected to the rear output.)

To Convert 220V to 110V

1.Make sure the appliance to be plugged in uses fewer watts than the transformer's rating.

2.Insert the voltage tap plug (located on the rear of the transformer) into the pair of holes corresponding to the local voltage standard. Check carefully to be sure no error has been made.

3.Attach the round-pin adapter to the transformer's power cord and connect it into the source of 200, 220, or 230 volts.

4.110 volts will be available at the front-panel outlet marked "110" volts when the power switch is turned on. (Please note that the front socket supports electrical devices with a current of up to 13A, devices above 13A must be connected to the rear output.)

Notes

1.Please note that on the back of the machine, input selection is in the upper row. And you need to connect the power wire by yourself.

2.To ensure the normal use of inductive loads, it is recommended to choose a transformer with a rated power of 3-5 times the load power.

3.Please allow the slight color difference caused by the shooting light and 1-3 cm error due to manual measurement, and make sure you do not mind before ordering. If you have problems, please feel free to contact us.

• Last and Durable: It is made of quality iron and has undergone various surface treatment processes such as polishing, painting, and high-temperature baking. Therefore, it has good hardness, wear resistance, corrosion resistance, and a long service life
• High Performance: This 8000W high-power converter can quickly and stably convert voltage between 110V and 220V, providing a reliable and convenient solution for changing voltage, and reducing line losses
• Safety Guard: The overload protection, over-temperature protection, class B insulation level, and uniform heat dissipation holes can ensure the stability and safety of the product during operation
• Thoughtful Design: The standard sockets, power indicator, one-click power switch, and clear identification, make it easy and convenient for you to use the product without worry
• Life Assistant: With 4 standard sockets, it adapts to various electrical appliances, achieving energy-saving, safe, and stable electricity consumption
• Ready to Go: The product is already assembled, so you can use it directly after a simple test when you receive it, which is very convenient
• Easy to Clean: Thanks to its simple construction and smooth surface, you can wipe the stains off its surface with a dry rag
