Impedance: 1 Ohm
Channels: 1
Channel Rated RMS Power at 14.4 V at 1 Ohm: 3600 Watts
Rated RMS Power at 14.4 V at 2 Ohms: 2400 Watts
Rated RMS Power at 14.4 V at 4 Ohms: 1500 Watts
Average Efficiency at 4 Ohms: 94%
Rated RMS Power at 12.6 V at 1 Ohm: 3000 Watts
Rated RMS Power at 12.6 V at 2 Ohms: 2100 Watts
Rated RMS Power at 12.6 V at 4 Ohms: 1150 Watts
RMS: 3600 Watts
Working Voltage: 10 to 16 Volts Max.
Current Draw: 280 A Min.
Power Wire: 4 Gauge Min.
Speaker Wire: 12 Gauge
Frequency Response: 10 Hz to 25 kHz
Filter Controls: Yes
Low Pass Filter: 50 Hz to 25 kHz
High Pass Filter: 10 Hz to 700 Hz
Built-In EQ Controls: Yes
Min. Input Sensitivity: 0.2 v
Signal Input: 1 Pair RCA
Signal to Noise: > 90 dB
Total Harmonic Distortion: <0,9%
Protection System: On Circuit Board
HECS Smart Fan Technology: Included
Heat Sink Type: Cast Aluminum
Dimensions ( H x W x L ): 3.19" x 7.25" x 8.25"
