VEVOR 5'' 3-Jaw Lathe Chuck Self-Centering Lathe Chuck for Grinding Drilling

(No ratings yet)

Key item features

Durable Construction: Constructed from HT300 material, this 5-inch 3-jaw lathe chuck features 20Cr steel jaws with 53HRC hardness and a 40Cr steel scroll with 45HRC hardness, ensuring superior hardness and rust resistance.
High Precision: The self-centering design incorporates a delicate bevel gear and three pinion gears, achieving a bearing tolerance of 0.05 mm / 0.002 inches for precise machining and structural stability.
Versatile Clamping: Equipped with both internal and external jaws, the chuck offers a clamping range of 0.1-5 inches (2.5-125 mm), accommodating various workpiece sizes, including larger industrial components.
Effortless Operation: Its simple and compact structure, combined with a built-in self-centering function, eliminates the need for repeated calibration, allowing for straightforward installation and use.
Broad Application: This self-centering lathe chuck is suitable for diverse applications such as metal machining, drilling, and milling, enhancing machining efficiency and operational flexibility.

Generated by AI

Specs

Material
Metal
Brand
VEVOR
Size
φ125 x 135 mm
Features
High Precision
Pieces
1
Model
K11-125

Current price is $77.99$77.99/ca

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Ships to

Arrives between May 29 - Jun 1

Sold and shipped by VEVOR Distribution Store

4.360346585117227 stars out of 5, based on 1962 seller reviews(4.4)

Report an issue with this seller

Free 30-day returns

About this item

Product details

Product Description

5'' 3-Jaw Self-Centering Lathe Chuck

The 5'' 3-jaw lathe chuck is made of high-strength HT300 material with strong compression resistance and long service life. It features an internal and external jaw to clamp larger-sized industrial components and a self-centering function to avoid repeated calibration.

Exceptional Durability

The 3-jaw lathe chuck is made of high-strength HT300 material with strong compression resistance and long service life. The chuck jaw is made of 20Cr steel with hardness ≥ 53HRC, and the scroll is made of 40Cr steel with hardness ≥ 45HRC.

Outstanding Operating Precision

The 3-jaw chuck has a self-centering function and a bevel gear to precisely control the accuracy of the clamped workpiece for precise machining. Bearing tolerance ≤ 0.05 mm / 0.002" ensures the lathe chuck's structural stability and high accuracy.

Adjustable Chuck Jaw

We provide you with two types of jaws, internal jaw, and external jaw, capable of clamping larger-sized industrial components. You can easily open and close the jaws by rotating the T-shaped key.

Easy to Use

This chuck consists of a chuck body, movable chuck, and jaw drive with a simple structure. When clamping a work part, the chuck is able to find and hold the center of the part automatically. All you need to do is install them in the correct order.

Wide Application

Whether you're working in woodworking, metalworking, drilling, or milling, our 3-jaw self-centering lathe chuck can meet your requirements for improved machining efficiencies and increased job flexibility and precision.

Self-Centering Function

The auto-centering function of the 3-jaw lathe chuck dramatically improves machining accuracy and work efficiency. You don't need to adjust and calibrate several times, and the jaws will automatically align to the centerline of the chuck.

Specifications

Item Model Number: K11-125

Chuck O.D: 5 in / 125 ± 5 mm

Clamping Range: 0.098-1.57"/2.5-40 mm

External Jaw Clamping Range: 1.78-5"/45-125 mm

Fixed Thread: 3-M8

Bore: φ30 mm

Surface Treatment: ＜Ra0.8, Oil Coated

Main Material: HT300

Net Weight: 10.8 lb / 4.9 kg

Product Size: φ125 x 135 mm

Jaw: 3-Jaw, 20Cr, ≥53HRC

Scroll: 40Cr, ≥45HRC

Package Content

1 x T-key

3 x Fixing Screws

1 x Reverse Jaws

1 x User Manual

Superior HT300 Material: Our 3-jaw lathe chuck is constructed from HT300 material, 20Cr steel chuck jaw with 53HRC hardness, and 40Cr steel scroll with 45HRC hardness. The lathe chuck is quenching hardened for superior hardness and rust resistance, providing outstanding working performance and reliability for both small and large workpieces.
High Precision: A high-precision machining process is adopted to ensure the structural stability and machining accuracy of the 3-jaw chuck. The self-centering lathe part contains a delicate bevel gear and three pinion gears, which help to achieve precise machining progress. Bearing tolerance is ≤0.05 mm / 0.002 in.
Internal & External Jaw: The 3-jaw self-centering lathe chuck is equipped with an internal jaw and external jaw to expand its clamping range, and the external jaws are capable of clamping larger-sized industrial parts. Clamping Range: 0.1-5 in/2.5 -125 mm. All you need to do is rotate it using the T-key and adjust it to fit your workpiece size and shape.
Simple & Easy Operation: The 3-jaw lathe chuck features a simple and compact structure, pursuing the best balance of function and reliability. The built-in self-centering function allows you to use it without repeated calibration. All you need to do is install it in the right order and use it with peace of mind.
Applicable to Various Lathes: Our self-centering lathe chuck is highly adaptable to meet your usage requirements, whether you are working in metal machining, drilling, or milling. By using our lathe chuck, you can improve machining efficiency and operational flexibility, achieving accurate and consistent results.
