Hero image 0 of CMM Touch Probe For M3 Thread Shank Ball Tip Carbide Stem CMM Stylus A-5000-7632 A-5004-2442 A-5003-3676 A-5004-7402 A-5003-0062, 0 of 5

CMM Touch Probe For M3 Thread Shank Ball Tip Carbide Stem CMM Stylus A-5000-7632 A-5004-2442 A-5003-3676 A-5004-7402 A-5003-0062

(No ratings yet)

Size:A-5003-0059

Key item features

【COMPREHENSIVE PROBE SET】 This CMM Touch Probe includes a carbide rod and a lightweight ball tip, designed for precision measurements in various applications. for use with threaded rods, it is available in multiple sizes to suit your specific needs.
【EXCEPTIONAL WEAR RESISTANCE】 Crafted from carbide, this probe offers outstanding wear resistance, longevity and reliability during use. It maintains stability even under temperature fluctuations, making it a great choice for demanding environments.
【ANTI-COLLISION DESIGN】 The built-in anti-collision protection enhances the probe's performance, reducing the risk of damage during operation. This feature is particularly beneficial in high-speed machining processes, allowing for smoother operation.
【NON-MAGNETIC AND NON-CONDUCTIVE】 Suitable for a wide range of surfaces including silicon carbide, this probe is non-magnetic and non-conductive, making it perfect for electrical discharge machining (EDM) applications without interference.
【SIZING REMINDER】 Please to check your sizing requirements before purchasing. Refer to the provided specifications for detailed dimensions and effective working radii to find the right fit for your projects.

Specs

Brand
Sufanic
Size
A-5003-0059

Current price is $23.29

Price when purchased online

Free shipping
Free 30-day returns

How do you want your item?

Ships to

Arrives between Jun 2 - Jun 5

Sold and shipped by Ylsvt

3.8461538461538463 stars out of 5, based on 39 seller reviews(3.8)

Report an issue with this seller

Free 30-day returns

About this item

Product details

Features:

* The ball head is light, wear-resistant, and stable when the temperature changes.

* The carbide rod is light and strong, with built-in anti-collision protection.

* Non-magnetic and non-conductive, suitable for delicate surfaces, silicon carbide surfaces, and electrical discharge machining (EDM) processes.

* The probe has good wear resistance and light transmittance.

* The industry standard of stylus technology. It is the hardest material and suitable for most applications.

Specifications:

Part Name: CMM Contact Probe

Model (optional): A-5000-7632, A-5004-2442, A-5003-3676, A-5004-7402, A-5003-0050, A-5003-0054, A-5003-0051, A-5003-0052, A-5003-0055, A-5003-005 7, A-5003-0053, A-5003-0056, A-5003-0058A-5003-0060A-5003-0062, A-5003-0059, A-5003-0061, A-5003-0063

Rod Material: Carbide

Color: As shown

Size: (as shown below)

A-5000-7632 for M3 threaded rod, Ø0.5mm red ball, carbide rod, 21mm long, effective working radius (EWL) 2mm

A-5004-2442 for M3 threaded rod, Ø1.0mm red ball, carbide rod, 20mm long, effective working radius (EWL) 12.5mm

A-5003-3676 for M3 threaded rod, Ø2.0mm red ball, carbide rod, 20mm long, effective working radius (EWL) 12.5mm

A-5004-7402 for M3 threaded rod, Ø3.0mm red ball, carbide rod, 20mm long, effective working radius (EWL) 14mm

A-5003-0050 for M3 threaded rod, Ø1.5mm Red ball, carbide shank, 21 mm long, effective working radius (EWL) 12.5 mm

A-5003-0054 for M3 threaded shank, Ø2.5 mm Red ball, carbide shank, 20 mm long, effective working radius (EWL) 12.7 mm

A-5003-0051 for M3 threaded shank, Ø1.5 mm Red ball, carbide shank, 30 mm long, effective working radius (EWL) 22.5 mm

A-5003-0052 for M3 threaded shank, Ø2.0 mm Red ball, carbide shank, 30 mm long, effective working radius (EWL) 22.8 mm

A-5003-0062 for M3 threaded shank, Ø5.0mm Red ball, carbide shank, 40 mm long, effective working radius (EWL) 40 mm

A-5003-0059 for M3 threaded shank, Ø3.0 mm Red ball, carbide shank, 50 mm long, effective working radius (EWL) 43.7 mm

A-5003-0061 for M3 threaded shank, Ø4.0 mm Red ball, carbide shank, 50 mm long, effective working radius (EWL) 46 mm

A-5003-0063 for M3 threaded shank, Ø5.0 mm Red ball, carbide shank, 50 mm long, effective working radius (EWL) 50 mm

Quantity: 1 piece

Package Contents:

1 x CMM Contact Probe

Note:

1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.

2.Please allow slight manual measurement deviation for the data.

【COMPREHENSIVE PROBE SET】 This CMM Touch Probe includes a carbide rod and a lightweight ball tip, designed for precision measurements in various applications. for use with threaded rods, it is available in multiple sizes to suit your specific needs.
【EXCEPTIONAL WEAR RESISTANCE】 Crafted from carbide, this probe offers outstanding wear resistance, longevity and reliability during use. It maintains stability even under temperature fluctuations, making it a great choice for demanding environments.
【ANTI-COLLISION DESIGN】 The built-in anti-collision protection enhances the probe's performance, reducing the risk of damage during operation. This feature is particularly beneficial in high-speed machining processes, allowing for smoother operation.
【NON-MAGNETIC AND NON-CONDUCTIVE】 Suitable for a wide range of surfaces including silicon carbide, this probe is non-magnetic and non-conductive, making it perfect for electrical discharge machining (EDM) applications without interference.
【SIZING REMINDER】 Please to check your sizing requirements before purchasing. Refer to the provided specifications for detailed dimensions and effective working radii to find the right fit for your projects.
