Ancel V6 Pro OBD2 Scanner Code Reader Bidirectional All System Auto Diagnostic Tool ABS TPMS 25+ Service Scan Tools

⁉️Why Choose the V6 PRO+ Bluetooth Diagnostic Tool?

ANCEL V6 PRO+ is a Bluetooth diagnostic scanner based on Android 10.0 tablet, works on over 10000 cars and covers most of the necessary common functions, such as Bi-directional control, active test, IMMO service (car key programmer), OE -level full system diagnosis, 25+ reset functions, etc. No matter you are a car DIYers or a professional mechanic, with this vehicle scanner you can easily find out what is wrong with your car, which parts need to be repaired and which parts do not. Besides, with this professional scan tool, you will get more information about your car and save unnecessary maintenance costs and time. It is definitely the most cost-effective and indispensable car diagnostic tool you are looking for!

✔️Newest Bi-directional Control/Active Test: Allows you to perform active test on various actuators to test its integrity & functionality. Every tiny detail would be captured and presented. Nothing would escape from its eyes.
✔️All System Diagnose: In-deepth diagnosis all available systems and modules to quickly pinpoint problems to help you fix them effectively.
✔️25+ Most Popular Reset Functions : Maximize the vehicle's potential while troubleshooting. Everything is in the palm of your hands with those functions on your side.
✔️Full OBDII Test Modes: Such as retrieve ECU information, read codes, clear codes, data stream display, DTC lookup, etc.
✔️ECU Cod-ing for some car models
Free WIFI update, No Additional Software/Subscription Fees!
✔️Clear the Language Barriers: Supports 11 languages, including English, French, Spanish, German, Russian, Italian, Polish, Portuguese, Dutch, Japanese and Korean.
✔️Robust Hardware Expansion: Bluetooth 5.0 wireless and easy connectivity, legible and responsive 8-inch touch screen, Android 10.0 operating system, simple and fast operation to help beginners get started.
✔️Long Endurance Battery: The 8000 mAh battery enables you to work from sunrise to sunset without charging. Never been bothered with the battery capacity! It’s time to say goodbye to the ‘’Low Battery Anxiety’’.
✔️Valuable Additional Functions: One-click screenshot, record video, camera (5.0 megapixel, auto focus, with flashlight), vehicle software, diagnostic report, data stream record & playback & print, feedback and more.
✔️Always on the Call: The ANCEL’s remote technical support service is provided by a professional team which leads by product managers. Every problem you encountered would be perfectly solved. You will never work alone!

👑VCI Box Parameters

Processor: ARM 32-bit Cortex processor
Input Voltage: DC 8-30V
Operating Temperature: -10 to 70°C （ 14-158°F ） ， relative
Humidity:<90%
Storage Temperature :-30 to 120°C （ -22-248°F ） ， relative
Humidity:<90%
Communication model :Bluetooth or USB
Protocols:
ISO 9141, ISO14230, ISO15765, ISO11898, SAE-J1850 VPW, SAE-1850
PWM, J1939, J1708, UDS, K/L lines, High speed CAN, Middle speed CAN, Low speed CAN and Single wire CAN

⚙️Tablet Specifications

CPU: Quad-core Cortex-A53 2.0GHz
GPU: G52 3EE MC1@800MHz
Operation system: Android 10.0
ROM :32 GB EMMC
RAM:2G LPDDR4
Display :8.0 inch IPS Multi-touch Capacitive Touch Screen
with 800*1280 resolution
Camera(rear): 5.0 Megapixel, AF with Flashlight
Connectivity WIFI: 802.11 b/g/n/ac Support Hot spot/ 2.4/5GHz
BlueTooth 5.0, USB 2.0, Type-C
HDMI: 1080P Output
TF Card ：(Support up to 32GB)
Audio ：Microphone， Dual Speakers
Power and Battery ：8000 mAh 3.7 V lithium-polymer battery
Input Voltage： 8V – 30V
Power Consumption： 6.5 W
Operating Temp.： -10 to 50°C (14 to 122°F)
Storage Temp：-20 to 60°C (-4 to 140°F)
Dimensions：(WxHxD) 270 mm(10.63 in) x 193 mm(7.60 in) x 38
mm(1.50 in)
Weight NW: 1.20 kg (2.65 lb) GW: 3.00 kg (6.61 lb)

📦Package List

1*V6 PRO Main tablet
1*Plastic box
1*OBD2 cable
1*Charge cable
1*US Plug/EU Plug
1*VCI Model
1*Manual
1*Password paper
