X1 HTU104VW1 12 in., 20A, 4 Outlets Hardwired Power Strip with USB

(No ratings yet)

At a glance

Brand: X-1

Dimensions: 1.61 x 1.61 x 1.61 Inches

Condition: New

Volts: 110 V

Watts: 1920 Watts

Has written warranty: Yes - Warranty Text

$69.28

Price when purchased online

Free 30-day returns

How do you want your item?

Shipping

Arrives Jun 26

$9.98

Pickup

Not available

Delivery

Not available

Sacramento, 95829

Arrives by Thu, Jun 26

|

Shipping fee $9.98

Sold and shipped by UnbeatableSale Local

3.994098554145766 stars out of 5, based on 3389 seller reviews(4.0)

Free 30-day returns

More seller options (1)

Starting from $81.22

About this item

Product details

Features

12"/0.30m Durable Steel Hardwired Power Strip, White
With Ears (Mounting Tabs) on both Ends, 2 x 0.67/17mm
4 White US NEMA 5-20R 20Amp Outlets, Vertical Orientation
2 USB Ports, (Type A) Output DC 5V/2.1A, Input AC 110-240V/0.5A/60Hz)
Hardwired without Power Cord for Mounting at Your Desired Location
ETL Approved and Listed (Conforms to UL 5, UL 1310 and CAN/CSA C22.2 No. 62)
Electrical Ratings: 125V/20A/60Hz/Recommended Max Load 1920W
6 Easily Punched off Knockouts on Each Side C (Top/Bottom Cover, Both Sides and Ends)
Back Cover Easily On/Off, Where Wires Are Connected
Wires Readily Striped for Easier Removal and Faster Installation
Great for Contractors, Electricians and Installers, as well as DIYers

Installation Guide:

Before installation, you may need to get a 3/8" wire clamp connector and 3 wire connectors (or terminal connectors). Decide your wire gauge, and ask store attendant for assistance what connectors you should get) from your local hardware, electric supply or home improvement stores
Minimum tools required: A fine to medium fine philips screw driver, and a pair of scissors, and a pair of mid size slip joint pliers, Turn off electricity in the house.Decide where to place this Hardwired Power Strip unit, Choose the knockout to be used for cord exit, then gently punch it off with the back of a screw driver or other tool handy,Unscrew the back cover off the unit with a philips screw driver
Take out the white/transparent plastic insulation sheet, and use a pair of scissors to cut a hole on it (about 3/4" in diameter, or big enough for) WHERE the wires will run through. If the bottom knockout on the back cover is to be used for wire connection, a wire clamp connector may not be needed, thus, please ignore step 6, 7 and 9 below
Put on the 3/4" wire clamp connector in place. Secure its installation by tightening the big ring screw (inside the casing) with the pair of slip joint pliers
Run the wires through the wire clamp connector, from outside into the Unit. In case bottom knockout on the back cover is to be used for wire connection, please run the wires through the back cover first and then the plastic insulation sheet, now with the knockout coin punched off, from outside to inside Match the colored wires and secure the wire connection with proper wire connectors Tighten the two pressure screws properly on the wire clamp connector Place the plastic insulation sheet back and screw the back cover on

Mount the unit:

For unit with ears (mounting tabs on both ends): mount the unit through the ears with screws provided
For unit without ears, place the unit where it is intended to be, mark where to install clips, secure the clips with screws provided. Then snap the unit in onto the clips
For models without ears up to 24, and models with ears above 30, mounting holes on the back cover could be used to secure the unit (but a unit CANNOT be installed with such mounting holes if the unit is to be placed against a wall/cabinet on the side since the unit cannot be reinstalled onto the back cover). Then, please mount the back cover first and then carefully screw the unit onto the back cover Turn electricity back on, it is ready to go

Specifications

Size: 12 in.
Outlets: 4
Ampere: 20A
Dimension: 12 x 1.61 x 1.- SKU: EDSTR1255
